Here at Switchback LED Lighting we also specialize in building and retrofitting headlight fittings.

We source a brand new aftermarket set of headlights.

Headlights pictured features Apollo 3 Shroud with Switchback Halo (Non RGBW)

Series 1 RG Colorado Custom Headlights features:

• D2S 3″ Projector retrofit – Standard gloss black and turbine shrouds each with the choice of Switchback or RGBW chasing halos.
• Housing Blackout – The standard reflector lens chrome is removed and painted matte/satin black.
• 55w HID bulbs with huge light output

LEAD TIME: We usually allow up to a month before the customer receives their order. This depends on how busy we are. If their is going to be any delays we will send you an email.

Halo Options:

• Switchback Halo – White halo with the option of flashing amber when you indicate. (Wiring from each indicator required)
• RGBW Chasing Halo – App controlled through bluetooth with over 200 chasing show modes and all standard static colours.

Projector Lens etching options:

• Custom (Send us your design)
• Honeycomb – Honeycomb pattern etched onto the lenses.
• None – No Lens etching

INSTALLATION

Some basic wiring is required

The Low, High, Park & Indicator function of the headlights are plug & play.

Halos: Will need a basic wiring harness (included):

Switchback Halos: A small Switchback controller is included for each headlight. This controller needs a Ground, Accessories/Park + and a Indicator + to operate the white and amber modes of the halo. These need to be spliced into your vehicles headlight plug using the included wiring connectors. (Ground can be connected to any ground point.

RGBW Chasing Halos: These halos will need the RGBW Controller and bluetooth box to operate them. This is completely plug & play besides a power and ground that needs to be connected. Where you connect this depends on when you want the halos to turn on. Normally customers will wire these to an Accessories or Ignition 12v + wire so the halos come on automatically.

Whats INCLUDED?:

• Your newly modified headlights (to spec of your choices made at checkout)
• Halo harness (If halos were chosen)
• 55w D2S HIDs complete with ballasts
• BA15s CANBUS compatible LED indicators x2
• T10 Canbus Parkers x2

LEGALITY FOR ROAD USE:

For off-road use only.

Please refer to our ADR law information page in the footer (bottom) of our site.
